NSS12 evo3S Multifunction Display with US Inland and Coastal C-MAP Charts

SIMRAD NSS12 evo3S Multifunction Display with US Inland and Coastal C-MAP Charts

Navigate Smarter. Fish Better. See Everything.

The SIMRAD NSS12 evo3S Multifunction Display with C-MAP® US Inland and Coastal Charts is the premium all-in-one chartplotter and fishfinder built for serious boaters. Whether you're sport fishing offshore, cruising coastal waters, or navigating inland lakes and rivers, the NSS12 evo3S delivers the performance, clarity, and connectivity you need to stay in control on the water. Powered by the iMX 8 high-performance processor, this 12-inch multifunction display (MFD) brings superfast response times, seamless screen transitions, and smooth multitasking to every outing.

The 12-inch SolarMAX™ IPS display produces 1200 nits of brightness and maintains ultra-wide 80° viewing angles from any position on the boat—even when viewed through polarized sunglasses. The optically bonded screen prevents condensation and fogging while withstanding the heat of direct sunlight, so you never lose sight of critical navigation data. Control is equally flexible: switch seamlessly between all-weather multi-touch touchscreen and full keypad operation with a rotary dial, or add optional OP50 remote controllers for hands-free convenience anywhere on board.

The built-in high-performance echosounder delivers 1kW CHIRP sonar across two independent 9-pin Xsonic ports, giving you the flexibility to run multiple transducers from a single display. Port 1 supports single-channel CHIRP and HDI transducers; Port 2 supports single-channel CHIRP and is compatible with TotalScan, LSS HD, and ForwardScan. Expand your fish-finding capability further with optional external sonar modules, including ActiveTarget™ live sonar, Active Imaging™, StructureScan™ 3D, SonarHub, BSM-2, and BSM-3.

The integrated 10 Hz GNSS receiver supports GPS, GLONASS, Galileo, Beidou, and QZSS with SBAS correction via WAAS, EGNOS, MSAS, and GAGAN, achieving a horizontal position accuracy of 3 meters and a cold-start time of just 50 seconds. Built-in Bluetooth and Wi-Fi allow seamless mirroring to iOS and Android devices, easy online software upgrades through any internet hotspot, and full connectivity to the Simrad App, giving you access to waypoints, charts, and your favorite fishing spots both on and off the water.

Industry-standard networking makes it easy to build a full multi-display helm system. Two 10/100 Mbit Ethernet ports, one NMEA 2000 Micro-C port, NMEA 0183 input and output, two composite video inputs, and dual MicroSD card slots provide broad compatibility with onboard electronics. The NSS12 evo3S integrates fully with Simrad HALO™ radar, SteadySteer™-enhanced autopilot systems for NAC-2 and NAC-3 computers fitted with RPU drive pumps, SonicHub2 audio, FusionLink, and third-party systems including CZone® digital switching, Mercury® Smart Tow® for wake shaping, and ITC Lighting control. Stay ahead of the weather with SiriusXM® WM-4 satellite weather and Fish Mapping™ (subscription required, North America only).

Preloaded C-MAP® US Inland and Coastal charts deliver comprehensive coastal and inland coverage with high-resolution bathymetry featuring 1-foot depth contours, C-MAP® Reveal embedded data for Florida, and Easy-Routing capabilities for simplified trip planning. Chart views support 3D and navigation perspectives, radar overlay, and compatibility with a wide range of third-party chart vendors. Store up to 6,000 waypoints, 500 routes, and 50 tracks with up to 12,000 track points.

Key Features

• High-Resolution SolarMAX™ IPS Display: A vivid 12-inch screen with 1200-nit brightness and ultra-wide 80° viewing angles keeps critical navigation and sonar data visible from anywhere on the helm, even through polarized sunglasses. Optical bonding eliminates condensation and fogging, so you stay focused on what matters.

• Advanced iMX 8 Processor: The iMX 8 high-performance processor powers superfast response times, seamless screen transitions, and smooth multitasking across charts, sonar, radar, and more, all without slowdown.

• Versatile 1kW CHIRP Echosounder: Two independent 9-pin Xsonic sonar ports let you connect multiple transducers simultaneously. Port 1 supports single-channel CHIRP and HDI; Port 2 supports single-channel CHIRP with TotalScan, LSS HD, and ForwardScan. Compatible with ActiveTarget™, Active Imaging™, StructureScan™ 3D, SonarHub, BSM-2, and BSM-3.

• Intuitive Touchscreen and Keypad Control: An all-weather multi-touch screen combined with a full keypad, rotary dial, and arrow keys delivers reliable control in any sea state. Add optional OP50 remote controllers for flexible helm management.

• Preloaded C-MAP® US Charts: Comprehensive US Inland and Coastal coverage with 1-foot depth contours, C-MAP® Reveal data for Florida, and Easy-Routing for simplified trip planning. Compatible with C-MAP and a wide range of third-party chart providers. Stores up to 6,000 waypoints, 500 routes, and 50 tracks.

• Built-In GPS and Wireless Connectivity: Integrated 10 Hz GNSS receiver supports GPS, GLONASS, Galileo, Beidou, and QZSS with SBAS correction. Built-in Wi-Fi and Bluetooth enable smartphone and tablet mirroring, online software updates, and access to the Simrad App for on- and off-water navigation.

• Full Networking and System Integration: Two Ethernet ports, NMEA 2000, NMEA 0183, dual MicroSD slots, and two composite video inputs connect seamlessly to your full electronics suite. Integrates with HALO™ radar, Simrad autopilot with SteadySteer™, SonicHub2, FusionLink, CZone® digital switching, Mercury® Smart Tow®, ITC Lighting, and SiriusXM® WM-4 weather (subscription required, North America only).

• Engine Integration and Autopilot Control: NMEA 2000 engine integration displays real-time engine data on screen. SteadySteer™ autopilot enhancement is compatible with NAC-2 and NAC-3 autopilot computers fitted with RPU drive pumps. Also supports Honda ECO mode, AIS, and Plan Position Indicator (PPI).

• Flexible Mounting and Storage: Low-profile flush-mount or bracket-mount options fit any helm configuration. Includes 16 GB internal storage and a 2-year manufacturer warranty.

What's in the Box
SIMRAD NSS12 evo3S Multifunction Display with C-MAP Charts, Sun Cover, Dash Mount Kit, Mounting Bracket, Edge Bezels, Power Cable, 4-Pin Connector

NSS Evo3 S Information Sheet
