SEAFLO 12V High Water Alarm Switch Panel
The SEAFLO SFASP1-01 High Water Alarm Switch Panel is a 12V DC safety monitoring device designed for high-water level detection and bilge pump control in marine applications. The panel integrates a three-position switch (AUTO / OFF / MANUAL) and a built-in alarm buzzer to provide both operational control and over-water-level alerting. The unit features a 12V power input, a 20A rated switch circuit, and a 16 AWG wire lead for straightforward connection to bilge pumps, float switches, or auxiliary alarm systems. The integrated 85 dB buzzer provides an audible warning when water reaches the connected float switch activation point. This panel is suitable for installation in boats, small vessels, and other marine environments requiring reliable bilge monitoring. The compact faceplate allows mounting in dashboards or bulkhead panels. Designed for use with any 12V DC bilge pump system, the panel provides continuous monitoring in AUTO mode, complete shutoff in OFF mode, and direct pump activation in MANUAL mode. It supports applications requiring a safety reminder system for high-water conditions, cabin water level monitoring, or general bilge management.
Key Features
- Integrated 3-Position Control – AUTO / OFF / MANUAL switch for operational control of 12V DC bilge pumps and high-water alert systems.
- Audible Alarm Indicator – Built-in 85 dB buzzer activates when paired float switch detects high-water level.
- Electrical Specifications – Rated for 12V DC input; 20A / 10A switch circuit; includes pre-wired 16 AWG leads for direct installation.
- Marine-Grade Construction – Durable panel housing designed for onboard environments, suitable for dashboards or bulkhead mounts.
- Compatible Systems – Works with standard 12V bilge pumps, SEAFLO float switches, and other high-water detection circuits.
